电子元器件 > 场效应管 > 其他场效应管 > 上海维安wmj40n50d1 500v 40a 0.1ω n-ch power mosfet
上海维安wmj40n50d1 500v 40a 0.1ω n-ch power mosfet
- 标 题：
- 上海维安wmj40n50d1 500v 40a 0.1ω n-ch power mosfet
- 发货地点：
- 广东省/深圳市/宝安区
- 产品类别：
- 其他场效应管
- 更新时间：
- 2023/12/27 15:37:01
商品详情
深圳市联大实业有限公司自创建以来，始终专注于仪器/仪表/工业自动化/电气行业，公司始终坚持“创新，品质，服务，节约，敬业，感恩”理念。吸收新创意，严把质量关口，全方位的服务跟踪，坚持做出高品质产品。本着“追求、员工、技术、精神、利益”10字宗旨，我们以质量为生命、时间为信誉、价格为竞争力的经营信念，经过多年的经验和积累，长时间产品的打磨以及完善的服务，立足于仪器/仪表/工业自动化/电气行业。
代理品牌：维安，芯迈(储能bms)，泰为（dsp），博思传感器，迈巨微afe，fairchildir仙童、everlight亿光、华邦、威士顿，st、nxp、wsidom、mps、ti、on、vishay及国内知名品牌二、三极管和各类偏冷门和工级民用ic产品。质量保证、可提供产品承认书，sgs环保报告。如需寻找任何电子元件，请随时与我们联系，谦虚有礼的专业人员会为您解答各种问题，提供专业服务。
【承诺】：本公司商品是100%原厂正品，环保产品!量多更加优惠！！！
！！(扫码咨询) ！！
葛先生：18926729362
地址：深圳市龙华区民治布龙路荔苑大厦b座1005室
| 产品型号 | rdson.typ | rdson.max | bvdss（v） | id(a)@ta=25℃ | vgs(v) (typ.) | 封装形式 | mpq |
| wmc1n40d1 | 9 | 11 | 400 | 1 | 1.6 | sot-23 | 3000 |
| wmo3n50d1 | 2.8 | 3.5 | 500 | 3 | 3.5 | to-252 | 2500 |
| wmo5n50d1 | 1.43 | 1.6 | 500 | 5 | 3.3 | to-252 | 2500 |
| wmo5n50d1b | 1.31 | 1.55 | 500 | 5 | 3.0 | to-252 | 2500 |
| wmk9n50d1b | 0.68 | 0.8 | 500 | 9 | 3.0 | to-220 | 50 |
| wml9n50d1b | 0.68 | 0.8 | 500 | 9 | 3.0 | to-220f | 50 |
| wmo9n50d1b | 0.68 | 0.8 | 500 | 9 | 3.0 | to-252 | 2500 |
| wmk13n50d1 | 0.35 | 0.48 | 500 | 13 | 3.0 | to-220 | 50 |
| wml13n50d1 | 0.35 | 0.48 | 500 | 13 | 3.0 | to-220f | 50 |
| wmk15n50d1b | 0.37 | 0.45 | 500 | 15 | 3.0 | to-220 | 50 |
| wml15n50d1b | 0.37 | 0.45 | 500 | 15 | 3.0 | to-220f | 50 |
| wmj18n50d1b | 0.28 | 0.35 | 500 | 18 | 3.0 | to-247 | 30 |
| wml18n50d1b | 0.28 | 0.35 | 500 | 18 | 3.0 | to-220f | 50 |
| wmk20n50d1 | 0.22 | 0.29 | 500 | 20 | 3.0 | to-220 | 50 |
| wml20n50d1 | 0.22 | 0.29 | 500 | 20 | 3.0 | to-220f | 50 |
| wmj20n50d1 | 0.22 | 0.29 | 500 | 20 | 3.0 | to-247 | 30 |
| wmj25n50d1b | 0.21 | 0.27 | 500 | 25 | 3.0 | to-247 | 30 |
| wml25n50d1b | 0.21 | 0.27 | 500 | 25 | 3.0 | to-220f | 50 |
| wmjp32n50d1 | 0.1 | 0.11 | 500 | 40 | 3.0 | to-247plus | 30 |
| wmj40n50d1 | 0.1 | 0.11 | 500 | 40 | 3.0 | to-247 | 30 |
| wmpn40n50d1 | 0.1 | 0.11 | 500 | 40 | 3.0 | to-3pn | 30 |
| wmi30n60d1 | - | 0.3 | 600 | 30 | 3.0 | to-3p | 30 |
| wmk4n65d1 | 2.4 | 2.75 | 650 | 4 | 3.3 | to-220 | 50 |
| wml4n65d1 | 2.4 | 2.75 | 650 | 4 | 3.3 | to-220f | 50 |
| wmo4n65d1 | 2.4 | 2.75 | 650 | 4 | 3.3 | to-252 | 2500 |
| wmk4n65d1b | 2.18 | 2.55 | 650 | 4 | 3.0 | to-220 | 50 |
| wml4n65d1b | 2.18 | 2.55 | 650 | 4 | 3.0 | to-220f | 50 |
| wmo4n65d1b | 2.18 | 2.55 | 650 | 4 | 3.0 | to-252 | 2500 |
| wmt4n65d1b | 2.18 | 2.55 | 650 | 4 | 3.0 | to-223 | 3000 |
| wmaa4n65d1b | 2.18 | 2.55 | 650 | 4 | 3.0 | to-251长 | 75 |
| wml7n65d1b | 1.13 | 1.3 | 650 | 7 | 3.0 | to-220fp | 50 |
| wmk7n65d1b | 1.13 | 1.3 | 650 | 7 | 3.0 | to-220 | 50 |
| wmo7n65d1b | 1.13 | 1.3 | 650 | 7 | 3.0 | to-252 | 2500 |
| wmh7n65d1b | 1.13 | 1.3 | 650 | 7 | 3.0 | to-251短 | 75 |
| wml7n65d1 | 1.16 | 1.4 | 650 | 7 | 3.2 | to-220fp | 50 |
| wmk7n65d1 | 1.16 | 1.4 | 650 | 7 | 3.2 | to-220 | 50 |
| wmo7n65d1 | 1.16 | 1.4 | 650 | 7 | 3.2 | to-252 | 2500 |
| wmh7n65d1 | 1.16 | 1.4 | 650 | 7 | 3.2 | to-251短 | 75 |
| wmo9n65d1 | 0.85 | 0.98 | 650 | 9 | 3.0 | to-252 | 2500 |
| wml10n65d1 | 0.8 | 0.95 | 650 | 10 | 3.0 | to-220f | 50 |
| wmk10n65d1 | 0.8 | 0.95 | 650 | 10 | 3.0 | to-220 | 50 |
| wml10n65d1b | 0.8 | 0.95 | 650 | 10 | 3.0 | to-220f | 50 |
| wmk10n65d1b | 0.8 | 0.95 | 650 | 10 | 3.0 | to-220 | 50 |
| wml12n65d1 | 0.58 | 0.78 | 630 | 12 | 3.0 | to-220f | 50 |
| wmk12n65d1 | 0.58 | 0.78 | 650 | 12 | 3.0 | to-220 | 50 |
| wml12n65d1b | 0.58 | 0.74 | 650 | 12 | 3.0 | to-220f | 50 |
| wmk12n65d1b | 0.58 | 0.74 | 650 | 12 | 3.0 | to-220 | 50 |
| wml16n65d1b | 0.48 | 0.58 | 650 | 16 | 3.0 | to-220f | 50 |
| wmk16n65d1b | 0.48 | 0.58 | 650 | 16 | 3.0 | to-220 | 50 |
| wml20n65d1b | 0.35 | 0.44 | 650 | 20 | 3.0 | to-220f | 50 |
| wmk20n65d1b | 0.35 | 0.44 | 650 | 20 | 3.0 | to-220 | 50 |
| wml10n70d1 | 0.88 | 0.98 | 700 | 10 | 3.0 | to-220fp | 50 |
| wml12n70d1 | 0.64 | 0.8 | 700 | 12 | 3.0 | to-220f | 50 |
| wml16n70d1 | 0.54 | 0.66 | 700 | 16 | 3.0 | to-220f | 50 |
| wml20n70d1 | 0.42 | 0.55 | 700 | 20 | 3.0 | to-220f | 50 |
| wmt1n80d1 | - | 11.5 | 800 | 1 | 4.0 | to223-3l | 3000 |
| wmo1n80d1 | - | 11.5 | 800 | 1 | 4.0 | to252 | 2500 |
| wmaa4n80d1 | 3.2 | 3.8 | 800 | 4 | 3.5 | to-251长 | 75 |
| wmh4n80d1 | 3.2 | 3.8 | 800 | 4 | 3.5 | to-251短 | 75 |
| wmaa4n80d1b | 3.8 | 4 | 800 | 4 | 3.2 | to-251长 | 75 |
| wmh4n80d1b | 3.8 | 4 | 800 | 4 | 3.2 | to-251短 | 75 |
| wmo4n80d1b | 3.8 | 4 | 800 | 4 | 3.2 | to-252 | 2500 |
| wmo6n80d1b | 1.8 | 2.2 | 800 | 6 | 3.5 | to-252 | 2500 |
| wml6n80d1b | 1.8 | 2.2 | 800 | 6 | 3.5 | to-220fp | 50 |
| wmo6n80d1 | 2.5 | 2.7 | 800 | 6 | 3.0 | to-252 | 2500 |
| wml6n80d1 | 2.5 | 2.7 | 800 | 6 | 3.0 | to-220fp | 50 |
| wmaa6n80d1b | 2.5 | 2.7 | 800 | 6 | 3.0 | to-251长 | 75 |
| wml7n80d1 | 1.5 | 1.6 | 800 | 7 | 3.0 | to-220fp | 50 |
| wml10n80d1b | 0.75 | 0.9 | 800 | 10 | 3.1 | to-220fp | 50 |
| wml10n80d1 | 0.91 | 1.15 | 800 | 10 | 4.0 | to-220fp | 50 |
| wmj10n80d1 | 0.91 | 1.15 | 800 | 10 | 4.0 | to-247 | 30 |
| wml4n90d1 | 3 | 3.5 | 900 | 4 | 3.5 | to-220f | 50 |
| wmk4n90d1 | 3 | 3.5 | 900 | 4 | 3.5 | to-220 | 50 |
| wmm4n90d1 | 3 | 3.5 | 900 | 4 | 3.5 | to-263 | 800 |
| wml4n90d1b | 2.63 | 3.2 | 900 | 4 | 3.7 | to-220f | 50 |
| wmk4n90d1b | 2.63 | 3.2 | 900 | 4 | 3.7 | to-220 | 50 |
| wmm4n90d1b | 2.63 | 3.2 | 900 | 4 | 3.7 | to-263 | 800 |
| wmo4n90d1c | 3.6 | 4.8 | 900 | 4 | 3.0 | to-252 | 2500 |
| wmk6n90d1 | 1.7 | 1.9 | 900 | 4 | 3.5 | to-220 | 50 |
| wml6n90d1 | 1.7 | 1.9 | 900 | 6 | 3.0 | to-220f | 50 |
| wmm6n90d1 | 1.7 | 1.9 | 900 | 6 | 3.0 | to-263 | 800 |
| wmk6n90d1b | - | 2.3 | 900 | 6 | 3.0 | to-220 | 50 |
| wml6n90d1b | - | 2.3 | 900 | 6 | 3.0 | to-220f | 50 |
| wmm6n90d1b | - | 2.3 | 900 | 6 | 3.0 | to-263 | 800 |
| wmk9n90d1 | 1.28 | 1.4 | 900 | 9 | 3.0 | to-220 | 50 |
| wml9n90d1 | 1.28 | 1.4 | 900 | 9 | 3.0 | to-220f | 50 |
| wmj9n90d1 | 1.28 | 1.4 | 900 | 9 | 3.0 | to-247 | 30 |
| wml9n90d1b | 1.0 | 1.2 | 900.0 | 9 | 3.1 | to-220f | 50 |
| wmj9n90d1b | 1.0 | 1.2 | 900.0 | 9 | 3.1 | to-247 | 30 |
| wmaa2n100d1 | 6.3 | 10 | 1000 | 2 | 3.5 | to-251长 | 75 |
| wmo2n100d1 | 6.3 | 10 | 1000 | 2 | 3.5 | to-252 | 2500 |
| wml4n100d1 | 2.2 | 2.5 | 1000 | 4 | 3.5 | to-220f | 50 |
| wml6n100d1 | 2.0 | 2.3 | 1000 | 6 | 3.5 | to-220f | 50 |
| wmm6n100d1 | 2.0 | 2.3 | 1000 | 6 | 3.5 | to-263-2 | 50 |
| wmj10n100d1 | 0.93 | 1.25 | 1000 | 10 | 3.5 | to-247 | 30 |
| wmj3n120d1 | 6.3 | 9 | 1200 | 3 | 3.5 | to-247 | 30 |
| wmo3n120d1 | 6.3 | 9 | 1200 | 3 | 3.5 | to-252 | 2500 |
| wmj12n120d1 | 1.2 | 1.4 | 1200 | 12 | 3.5 | to-247 | 30 |
| wmk3n150d1 | 5.5 | 8.2 | 1500 | 3 | 3.5 | to-220 | 50 |
| wmx3n150d1 | 5.5 | 8.2 | 1500 | 3 | 3.5 | to-3pf | 30 |
| wmj3n150d1 | 5.5 | 8.2 | 1500 | 3 | 3.5 | to-247 | 30 |
| wml3n150d1 | 5.5 | 8.2 | 1500 | 3 | 3.5 | to-220f | 30 |
| wmm3n150d1 | 5.5 | 8.2 | 1500 | 3 | 3.5 | to263-2 | 800 |
| wmx4n150d1 | 5.4 | 6.2 | 1500 | 4 | 3.5 | to-3pf | 30 |
| wmj4n150d1 | 5.4 | 6.2 | 1500 | 4 | 3.5 | to-247 | 30 |
| wmj9n150d1 | 2.9 | 4.2 | 1500 | 9 | 3.5 | to-247 | 30 |
| wmj11n150d1 | 2.4 | 3.2 | 1500 | 11 | 3.5 | to-247 | 30 |
